Standard Functions
Test Bosch piezo and Denso piezo injectors
Test Bosch,Denso Dlephi,Siemens injectors
Test Bosch IV 4-needle, carter common rail ,MTU injectors
Test the oil injection and return of 4 injectors simultaneously and generate the code at the same time
Coding Function
Bosch 7/8/9/10 digit IQA code
Bosch piezoe IMA/ISA code
Denso 16/22/24/26/30/32 digit correction code
Delphi IC2,IC2;Siemens IIC;Cummins XPI
Hardware Configuration
Built-in air pump;8 flow meters
Bosch original CP4 common rail pump
4 sets of pneumatic fixture, compatible with internal/external injectors
19 inch industrial computer,touch screen and keyboard dual mode operation
Remote software upgrade, data update
Technical Parameters
| Output | 7.5KW |
| Speed | 0-2500RPM |
| Speed Control Model | Frequency Converter |
| Power | 3-Phase 4-Wire 380V 50/60HZ |
| Cooling System | 2P forced cooling unit |
| Rail Pressure | 0-2700 Bar |
| Rail Pressure Precision | ±5 Bar |
| Sensor range | 0.008-2L/min |
| Oil Tank Volume | 35L |
| Fuel Temperature | 40±2℃ |
| Filter Precision | <5 μm |
| Air Pressure | 4 kg |
| Noise Level | < 85 dB |
| ECU Internal Boost | 0-200 VDC (Max) |
| Control Circuit Voltage | DC48V / DC24V |
| Dimensions | 1660*1300*1580 mm |
| Net Weight | 515 kg |
